RX-2 GP Style Multifunction

The RX‑2 is probably one of our best seller. Its unique color changeable backlight makes it a very popular instrument. The illuminated needle with LED pointer makes it very easy to read even at night. This instrument features many different functions such as speed, odometer, tripmeter, RPM, shift light, temperature, indicator lights and many other cool functions. Set yourself apart with the RX‑2 !

 Specifications (R= Range U=Unit)

  • Speedometer
    R: 0 ~ 225 MPH (0 ~ 360 km/h)
    U: MPH or km/h (alternative)
  • Odometer
    R: 0 ~ 99,999 miles (km) | U: 1 mile (km)
  • Tripmeter A/B
    R: 0 ~ 999.9 miles (km) | U: 0.1 mile (km)
  • Speeding warning light
    R: 20 ~ 110 MPH (30 ~ 180 km/h)
    U: 5 MPH (km/h)
  • Top speed record
    R: 0 ~ 225 MPH (0 ~ 360 km/h)
    U: 1 MPH(km)
  • Tire circumference
    R: 300 ~ 2,500 mm | U: 1 mm
    Sensitive point: 1 ~ 60
  • Tachometer
    R: 0~15,000 RPM | U: 100 RPM
  • RPM shift‑light
    R: 5,000 ~ 15,000 RPM | U: 100 RPM
  • Maximum RPM record
    R: 0 ~ 15,000 RPM
  • Stroke / piston setting
    2 stroke: 1, 2, 3, 4 pistons
    4 stroke: 1, 2, 3, 4, 5, 6, 8, 10, 12 pistons
  • Digital temperature (Water & Oil)
    R: 32 ~ 248 °F (0 ~ 120 °C)
    U: 0.1 ˚F or ˚C (alternative)
  • Temperature level meter
    R: 68 ~ 248 °F (20 ~ 120 °C)
    R: 10 levels | U: 1 level = 50 °F or 10 °C (alternative)
  • Over Temperature warning (Water & Oil)
    R: 140 ~ 248°F (60 ~ 120°C) | U: 1°F (°C)
  • Top temperature record
    R: 32 ~ 248 °F (0 ~ 120 °C)
  • Fuel meter
    R: 10 levels | U: 1 level = 10 %
  • Fuel resistance
    R: 100 Ω / 510 Ω / no display
  • Low fuel warning
    R: 10 ~ 50% | U: 10%
  • Clock
    R: 24 H format
  • Target speed timer
    D: 20 ~ 225 MPH (30 ~ 360 km/h)
    R: 5 MPH (km/h)
  • Target distance timer
    D: 1/32 ~ 20/32 mile (50 ~ 1,000 m)
    U: 1/32 mile (50 m)
  • Top speed timer
    Speed : 0 ~ 225 MPH (0 ~ 360 km/h)
    Distance : 0 ~ 3,280 feet (0 ~ 999 m)
    RPM : 0 ~ 15,000 RPM
    Timer : 0 ~ 9’59”99
  • Indicator lights
    Neutral / High beam / Turn signals / Check engine / Oil level / Temperature / Speeding / RPM shift light

  • Effective temperature range
    14 ~ 140 °F (‑10 ~ 60 °C)

  • Effective voltage
    DC 12 V

  • Sensor included
    Passive speed sensor : BF019005
    Temperature sensor: BF030125

$509.95 CAD

In stock

Part number
